CHEVROLET SILVERADO 1500 UTE 6.2L V8 2020 - ON Catback Exhaust System

• Size - Single 3" into Twin 2 3/4"

• Flex - Yes

• Muffler Delete Pipe - No

• Muffler - Yes

• Stainless Steel

• Fitting Kit Included

WHAT’S IN THE BOX

Intermediate Pipe
A full 409 Grade Stainless Steel intermediate pipe has been designed to fit up to the existing OE ball joint clamp at the back of the cats. From the formed end a single 3” pipe enters a full stainless steel braided flexible bellow into a pressed Y-Piece which separates the flow early into twin 3” pipes.

Muffler Assembly
The twin 3" pipes then flow into a specifically designed sports chambered muffler to produce the deep rumble the Silverado 1500 deserves.

Over Axle Assembly
Efficient selection of 2.75" over axle pipes allows the exhaust gasses to flow through the system at the same rate, improving performance and sound. A single over axle section coupled with a LHS extension pipe bolts to the rear of the muffler assembly with only 4 bolts. Solid 12mm hangers and laser cut braces are used to ensure durability and fitment ease.

Tailpipes
The same 2.75" Mandrel Bent 409 Stainless tailpipes exit the over axle assembly and locate into the factory exhaust finishers. For added adjustment and ease of fitment, the tailpipes are secured into the flared sections by using Stainless Steel clamps and adjustable rear hangers.

Full Fitting Kit
As with all Outlaw Performance Exhaust kits, our CHEV01SS System is supplied with high quality fasteners, gaskets and clamps. A full range of accessories for all vehicles can also be purchased separately by contacting one of our distributors nationwide.

CLICK TO VIEW AND DOWNLOAD THE BROCHURE
